Infiniti FX50 II (2008-2012) sound sig gnd Wiring diagram

108 109 RR SOUND SIG (+) RF SOUND SIG (+) 137 138 139 FM SUB AM-FM MAIN ANTENNA AMP ON SIG A/T ASSEMBLY (ON TRANSMISSION) AM/ FM ANTENNA BASE ANTENNA AMPLIFIER AUX IMAGE GND AUX IMAGE SIG AUX IMAGE SIG CAMERA IMAGE SIGNAL SHIELD AUX IMAGE SIG GND SHIELD SHIELD AUXILIARY INPUT JACK AV COMM (H) AV COMM (L) AV CONTROL UNIT BACKUP LAMP RELAY (RIGHT SIDE OF DASH) BLK WIRE BLU WIRE BRN WIRE CAMERA GND CAMERA PWR SPLY CAN L CAN-H COMPUTER DATA LINES SYSTEM EJECT SIG FUSE 3 GLASS ANTENNA (FM SUB) GRN WIRE HOT IN ON OR START HOT IN ON OR START FUSE BLOCK (J/B) (LEFT KICK FUSE 4 PANEL) L SOUND SIG (+) LR SOUND SIG (-) LF SOUND SIG (-) LT BLU WIRE LT GRN WIRE MAIN MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE PARKING BRAKE SWITCH PNK WIRE PPL PPL PNK WIRE R SOUND SIG (+) RED WIRE REV LAMP RLY ROD ANTENNA (AM/FM MAIN) SATELLITE ANTENNA SHIELD SHIELD PNK WIRE SHIELD SHIELD TEL VOICE SIG (+) TEL VOICE SIG (-) SIG AMP ON SOUND SIG GND SOUND SIG GND L SOUND SIG (+) R SOUND SIG (+) SPD SIG SW GND TCM (TRANSMISSION CONTROL MODULE) UNIFIED METER, A/C AMPLIFIER (CENTER OF DASH) VEHICLE SPEED SIG PARKING BRAKE SIG REVERSE SIG IGNITION SIG EJECT SIG PPL WHT WIRE YEL WIRE
