Infiniti FX50 II (2008-2012) right door push switch on Wiring diagram
This page shows the only wiring diagram for the component.right door push switch on, which is found in the car Infiniti FX50 II (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right door push switch on (1 of 1)
10 11 12 13 14 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER CONSOLE INDIRECT LEFT VANITY ILLUMINATION MIRROR LAMP
COMPUTER DATA LINES SYSTEM
DOOR
FUSE 44
FUSE 53
FUSIBLE LINK F
FUSIBLE LINK HOLDER (RIGHT REAR
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION RELAY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT
LEFT PUSH SWITCH DOOR
LT BLU WIRE
MAIN SWITCH DOOR ALL ON OFF
MAP LAMP
OF ENGINE COMPT)
ORG/ WIRE
PERSONAL LAMP
PNK 1 2 3 4 WIRE
PNK 2 3 4 5 WIRE
PNK WIRE
PPL
PPL/ PPL/ PPL/
RED WIRE
RIGHT
RIGHT DOOR PUSH SWITCH ON
RIGHT VANITY MIRROR LAMP
ROOF MODULE)
TAIL LAMP RELAY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> RIGHT DOOR PUSH SWITCH ON
