Infiniti FX50 II (2008-2012) ppl 20 25 turn sig rr turn sig lr Wiring diagram
This page shows the only wiring diagram for the component.ppl 20 25 turn sig rr turn sig lr, which is found in the car Infiniti FX50 II (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl 20 25 turn sig rr turn sig lr (1 of 1)
11 13 BAT (FUSE) GND
124 150 PASSENGER DOOR SW DRIVER DOOR SW
17 18 TURN SIG RF TURN SIG LF
2 3 TURN, BUZZER
53 54 55 71 56 72 IGN BAT GND GND CAN-H CAN-L
68 69 REAR RH DOOR SW REAR LH DOOR SW
7 27 COMM (AMP-METER) COMM (METER-AMP)
91 90 CAN-H CAN-L PNK WIRE
BAT (F/L)
BCM (BODY CONTROL MODULE) (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE 11
FUSE 3
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK L
GRN WIRE
GRY WIRE
HAZARD ON
HAZARD SW
HOT AT ALL TIMES
HOT IN ON OR START
LAMP
LEFT "C" PILLAR)
LEFT LICENSE PLATE RIGHT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN WIRE
MULTI-FUNCTION SWITCH (HAZARD SWITCH)
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PPL
PPL 20 25 TURN SIG RR TURN SIG LR
RED WIRE
RIGHT REAR COMBINATION LAMP
SIDE MARKER
SIDE MARKER TURN
TAIL STOP
TURN
UNIFIED METER, A/C AMPLIFIER (CENTER OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> PPL 20 25 TURN SIG RR TURN SIG LR
