Infiniti FX50 II (2008-2012) pnk can-l can-h Wiring diagrams
This page contains all the electrical diagrams for the component. pnk can-l can-h, in which he is found in the car Infiniti FX50 II (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk can-l can-h (1 of 2)
1 2 3 BAT (F/L) PWR SUPPLY (BAT) PWR SUPPLY (RAP)
118 116 PNK WIRE
119 132 DR DOOR SEN PWR WDW SW COMM
17 19 4 13 5 8 9 RH FR TURN SIG ROOM LAMP TIMER BAT SAVE GND
25 20 LR TURN SIG RR TURN SIG PPL
38 39 PPL
80 81 92 IMMO ANT CTRL IMMO ANT SIG KEY SLOT ILL
99 96 SHIFT P A/T PWR SUPPLY
ACC LED
BAT FUSE
BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
COMPUTER DATA LINES SYSTEM
CONSOLE INSIDE KEY ANTENNA (UNDER CENTER CONSOLE)
DOOR LOCK ACTUATOR
DOOR LOCK, UNLOCK SWITCH
DR UNLOCK OUT (RR)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK L
GRN WIRE
GRN/ LT WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE KEY ANTENNA (INSTRUMENT CENTER) (CENTER OF DASH)
INTERIOR LIGHTS SYSTEM (RIGHT SIDE OF DASH)
KEY CYLINDER SWITCH
LEFT FRONT OUTSIDE HANDLE (REQUEST SWITCH)
LEFT FRONT OUTSIDE KEY ANTENNA (INTEGRAL TO LEFT FRONT DOOR HANDLE ASSEMBLY)
LF FR TURN SIG
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASS DR ANT- PASS DR ANT+ DRV DR ANT- DRV DR ANT+
PNK CAN-L CAN-H WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOWS SYSTEM
PPL
PPL PPL DR UNLOCK OUT (PASS) DR LOCK OUT (ALL) DR UNLOCK OUT (DRV)
RED WIRE
RIGHT FRONT OUTSIDE KEY ANTENNA (INTEGRAL TO RIGHT FRONT DOOR HANDLE ASSEMBLY)
UNLOCK LOCK FULL STROKE FULL STROKE
UNLOCK SENSOR
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (1 of 4) -> PNK CAN-L CAN-H WIRE
Wiring diagram pnk can-l can-h (2 of 2)
1 2 3 BAT (F/L) PWR SUPPLY (BAT) PWR SUPPLY (RAP)
118 116 PNK WIRE
119 132 DR DOOR SEN PWR WDW SW COMM
17 19 4 13 5 8 9 RH FR TURN SIG ROOM LAMP TIMER BAT SAVE GND
25 20 LR TURN SIG RR TURN SIG PPL
38 39 PPL
80 81 92 IMMO ANT CTRL IMMO ANT SIG KEY SLOT ILL
99 96 SHIFT P A/T PWR SUPPLY
ACC LED
BAT FUSE
BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
COMPUTER DATA LINES SYSTEM
CONSOLE INSIDE KEY ANTENNA (UNDER CENTER CONSOLE)
DOOR LOCK ACTUATOR
DOOR LOCK, UNLOCK SWITCH
DR UNLOCK OUT (RR)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK L
GRN WIRE
GRN/ LT WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE KEY ANTENNA (INSTRUMENT CENTER) (CENTER OF DASH)
INTERIOR LIGHTS SYSTEM (RIGHT SIDE OF DASH)
KEY CYLINDER SWITCH
LEFT FRONT OUTSIDE HANDLE (REQUEST SWITCH)
LEFT FRONT OUTSIDE KEY ANTENNA (INTEGRAL TO LEFT FRONT DOOR HANDLE ASSEMBLY)
LF FR TURN SIG
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASS DR ANT- PASS DR ANT+ DRV DR ANT- DRV DR ANT+
PNK CAN-L CAN-H WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOWS SYSTEM
PPL
PPL PPL DR UNLOCK OUT (PASS) DR LOCK OUT (ALL) DR UNLOCK OUT (DRV)
RED WIRE
RIGHT FRONT OUTSIDE KEY ANTENNA (INTEGRAL TO RIGHT FRONT DOOR HANDLE ASSEMBLY)
UNLOCK LOCK FULL STROKE FULL STROKE
UNLOCK SENSOR
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (1 of 4) -> PNK CAN-L CAN-H WIRE
