Infiniti FX50 II (2008-2012) mirror switch Wiring diagrams
This page contains all the electrical diagrams for the component. mirror switch, in which he is found in the car Infiniti FX50 II (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mirror switch (1 of 2)
1 2 PPL
A/T SHIFT SELECTOR (DETENTION SWITCH)
BACK- WARD
BACKWARD
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
DRIVER SIDE FRONT SEAT
FOR- WARD
FORWARD/
GRN WIRE
GRY WIRE
IND 2 MEMORY
LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
MEMORY 1 SWITCH
MEMORY 2 SET SWITCH SWITCH
MEMORY IND 1
MIRROR SWITCH
OFF
OFF OFF
ON ON
OPEN/CLOSE SWITCH
ORG/ WIRE
PNK WIRE
PPL
PPL 1 2 3 4 5 6
PPL PNK WIRE
RED WIRE
RIGHT LEFT
SEAT MEMORY SWITCH
UP DN OFF
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (2 of 3) -> MIRROR SWITCH
Wiring diagram mirror switch (2 of 2)
BLK WIRE
BLU WIRE
CHANGE OVER SWITCH
CLOSE OPEN
DEFOGGER SYSTEM
DIODE
DOOR MIRROR REMOTE CONTROL SWITCH
DRIVER SIDE DOOR MIRROR (FRONT OF DRIVER'S DOOR)
FUSE 19
FUSE BLOCK (J/B) (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT IN ON OR ACC
LT BLU WIRE
LT GRN WIRE
MIRROR SWITCH
OPEN CLOSE
OPEN/CLOSE SWITCH
ORG/ WIRE
PASSENGER SIDE DOOR MIRROR (FRONT OF FRONT PASSENGER'S DOOR)
PNK WIRE
PPL
RED WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> MIRROR SWITCH
