Infiniti FX50 II (2008-2012) left front corner sensor Wiring diagrams
This page contains all the electrical diagrams for the component. left front corner sensor, in which he is found in the car Infiniti FX50 II (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front corner sensor (1 of 2)
15 16 SHIELD
AV COMM (H)
AV COMM (L)
BATTERY
BLK WIRE
BRN WIRE
CENTER SPEAKER
COMPUTER DATA LINES SYSTEM
FUSE 4
FUSE BLOCK (J/B) (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT IN ON OR START
K LINE
LEFT FRONT CORNER SENSOR
LEFT REAR CORNER SENSOR
LEFT REAR SQUAWKER
LF CORNER SENS
LR CORNER SENS
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL
PPL PPL
PPL PPL 7 8
RED WIRE
RF CORNER SENS
RIGHT FRONT CORNER SENSOR
RIGHT FRONT SQUAWKER
RIGHT REAR CORNER SENSOR
RIGHT REAR SQUAWKER
RR CORNER SENS
SENS GND
SHIELD
SHIELD 17 18
SONAR CONTROL UNIT
WHT WIRE
WOOFER
WOOFER AMP
YEL WIRE
Go to component -> Navigation circuit (3 of 6) -> LEFT FRONT CORNER SENSOR
