Infiniti FX50 II (2008-2012) fuse 10 fuse 9 fuse 6 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 10 fuse 9 fuse 6, in which he is found in the car Infiniti FX50 II (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 10 fuse 9 fuse 6 (1 of 2)
7 27 34 14 AMP-METER METER-AMP AMP-LCD LCD-AMP
71 55 41 53 56 72 GND GND
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER FRONT DOOR SWITCH (LEFT "B" PILLAR)
FUSE 10 FUSE 9 FUSE 6
FUSE 11
FUSE 19
FUSE 4 FUSE 3
FUSE 7
FUSE BLOCK (J/B) (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IGN CAN-H CAN-L
IND
KEY IND
LT GRN WIRE
ORG/ WIRE
PASSENGER FRONT DOOR SWITCH
PNK WIRE
PPL
RED WIRE
SECURITY
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
UNIFIED METER CONTROL UNIT
UNIFIED METER, A/C AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (4 of 4) -> FUSE 10 FUSE 9 FUSE 6
