Infiniti FX50 II (2008-2012) eng tacho Wiring diagram
This page shows the only wiring diagram for the component.eng tacho, which is found in the car Infiniti FX50 II (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eng tacho (1 of 1)
1 2 3 4 5 EPS SOL+
5.0L 3.5L
6 7 8 9 10 11 12 GND
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENG TACHO
ENGINE CONTROL MODULE (ECM) (RIGHT END OF DASH)
EPS SOL-
FUSE 45
GRN WIRE
HOT W/ IGNITION RELAY ENERGIZED
IGN
LT GRN WIRE
POWER STEERING CONTROL UNIT (RIGHT SIDE OF DASH)
POWER STEERING SOLENOID VALVE
RED WIRE
TACHO
VSP
Go to component -> Electronic power steering circuit, without ras -> ENG TACHO
