Cooling fan circuit for Infiniti FX45 I facelift (2005-2009)

+BATT MOTOR FAN-3 MOTOR FAN-1 GND (SIGNAL) GND (POWER) +BATT +IG CAN-L CAN-H BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE CAN-L CAN-H AVCC PD- (PDPRES) COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR (FRONT OF ENGINE COMPARTMENT) COOLING FAN RELAY 1 COOLING FAN RELAY 3 ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT END OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) FUSE 71 FUSE 78 FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPARTMENT) FUSIBLE LINK E FUSIBLE LINK G FUSIBLE LINK HOLDER (RIGHT REAR OF ENGINE COMPARTMENT) GND-A TW PRES GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION RELAY LT GRN WIRE LT GRN/RED WIRE PNK (OR PNK (OR WIRE PNK WIRE PPL RED WIRE REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPARTMENT) WHT WIRE WHT/RED WIRE
