Infiniti FX45 I facelift (2005-2009) rear lifting motor lifting sensor Wiring diagram

A/T DEVICE (UNDER FRONT OF CENTER CONSOLE) ADP STEERING SWITCH BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE DN UP FRONT LIFTING MOTOR LIFTING SENSOR FWD BWD GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE LT BLU WIRE LT GRN WIRE PARK POSITION SWITCH REAR LIFTING MOTOR LIFTING SENSOR RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE TELESCOPIC SWITCH TILT SWITCH UP DN WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/WHT WIRE
