Infiniti FX45 I facelift (2005-2009) hot in on or start fuse 14 Wiring diagram
This page shows the only wiring diagram for the component.hot in on or start fuse 14, which is found in the car Infiniti FX45 I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on or start fuse 14 (1 of 1)
A/T CHECK IND
ABS IND.
AIR BAG IND
AWD IND
BELT IND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT)
BRAKE IND
BUZZER
CHARGE IND
CLOCK BAT ILL+
COMBINATION METER
DOOR IND
FUEL IND
FUEL TACHOMETER GAUGE
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GND (ILL)
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HIGH BEAM IND
HOT AT ALL TIMES FUSE 22
HOT IN ACC OR ON FUSE 6
HOT IN ON OR START FUSE 14
ILLUM CONTROL ILLUM SWITCH
INSERTED
INTERIOR LIGHTS SYSTEM WARNING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
KEY IND (GREEN)
KEY SWITCH
KEY SWITCH WITHDRAWN
KEY SWITCH, IGNITION KNOB SWITCH PUSHED IGNITION KNOB SWITCH
LDW IND
LEFT TURN IND
LT GRN WIRE
MALFUNCTION IND LAMP
METER ILLUM
METER SIDE SWITCH
NCA WIRE
ODO/TRIP METER ILLUM
ODO/TRIP METER SWITCH TRIP RESET TRIP TRANSFER
OIL IND
P-SHIFT IND
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PPL
PPL 4 5 6 7
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
REMOVED
RIGHT TURN IND
RUN-FLAT TIRE IND
SET IND CRUISE IND (GREEN)
SLIP IND
SNOW IND
SPEEDO- METER
STARTING/CHARGING SYSTEM
TIRE PRESSURE IND
UNIFIED METER CONTROL UNIT
VDC OFF IND
W/ INTELLIGENT KEY
W/ INTELLIGENT KEY KEY IND
W/ INTELLIGENT W/O INTELLIGENT KEY KEY
W/ LDW
W/O INTELLIGENT KEY
WARNING SYSTEM
WASHER IND
WATER TEMP GAUGE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WIPER/WASHER SYSTEM
Go to component -> Instrument cluster circuit (1 of 2) -> HOT IN ON OR START FUSE 14
