Infiniti FX45 I facelift (2005-2009) acc sw fr door sw rr door sw auto lt in tpms mode trigger sw Wiring diagram

ACC SW FR DOOR SW RR DOOR SW AUTO LT IN TPMS MODE TRIGGER SW AIR CONDITIONING SYSTEM EXTERIOR LIGHTS SYSTEM AIRCON SW BLWR FAN SW HAZARD SW ANTI-THEFT SYSTEM BACK DOOR SW REAR WIPER AUTO STOP BAT SAVER OUTPUT BAT (FUSE) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS, INTERIOR LIGHTS SYSTEMS DOOR LOCKS, INTERIOR LIGHTS, ANTI-THEFT SYSTEMS DOOR LOCKS, INTERIOR LIGHTS, WARNING SYSTEMS DOOR LOCKS, WARNING, INTERIOR LIGHTS, ANTI-THEFT SYSTEMS FL DOOR SW RL DOOR SW PNK WIRE FUSE 1 FUSE 22 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK M GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM WARNING SYSTEM HEADLIGHTS, INTERIOR LIGHTS, EXTERIOR LIGHTS, WIPER/WASHER SYSTEMS HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START INTERIOR LIGHTS, MIRRORS SYSTEM LT BLU WIRE LT GRN WIRE NATS ANTENNA AMP ORG/ WIRE OUTPUT 5 OUTPUT 4 OUTPUT 3 OUTPUT 2 OUTPUT 1 KEY SW IGN SW CAN-H CAN-L PNK WIRE PNK/BLK WIRE PNK/BLU WIRE POWER TOPS, POWER WINDOWS SYSTEMS PPL PPL KEY RING OUTPUT INPUT 5 INPUT 4 INPUT 3 INPUT 2 INPUT 1 PPL/WHT WIRE REAR WIPER MTR OUT RED WIRE RED/BLK WIRE RED/YEL WIRE RR DEF SW WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIPER/WASHER SYSTEM YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
