Wiring diagram right end of dash) (21 of 26)
BACK DOOR CLOSURE CONTROL UNIT (LOWER LEFT SIDE OF BACK DOOR)
BACK DOOR CLOSURE MOTOR (LOWER CENTER OF BACK DOOR)
BACK DOOR OPEN OUTPUT
BACK DOOR OPENER SWITCH
BLK WIRE
BLU WIRE
DOOR LOCKS SYSTEM
FUSE 18
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
INTELLIGENT KEY UNIT (LEFT END OF DASH)
LT GRN WIRE
OFF
ON OFF OFF OFF
ON ON ON
OPEN SWITCH CLOSE SWITCH DOOR SWITCH HALF LATCH SWITCH
OPEN/ CLOSE MOTOR
ORG/ WIRE
PNK BACK DOOR OPEN SWITCH WIRE
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
YEL WIRE
Go to component -> Power liftgate circuit, with intelligent key unit -> RIGHT END OF DASH)
Wiring diagram right end of dash) (22 of 26)
BACK DOOR CLOSURE CONTROL UNIT (LOWER LEFT SIDE OF BACK DOOR)
BACK DOOR CLOSURE MOTOR (LOWER CENTER OF BACK DOOR)
BACK DOOR OPENER SWITCH
BLK WIRE
BLU WIRE
CLOSE SW
DOOR CONDITION SW
DOOR LOCKS SYSTEM
FRONT PASSENGER SIDE DOOR LOCK ASSEMBLY (REAR OF FRONT PASSENGER DOOR)
FUSE 18
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
HALF LATCH SW
HOT AT ALL TIMES
LT GRN WIRE
MOTOR CLOSE OUT
OFF
ON ON OPEN ON OFF OFF CLOSED
OPEN SWITCH CLOSE SWITCH HALF HATCH SWITCH DOOR SWITCH
OPEN/ CLOSE MOTOR
ORG/ WIRE
OUTSIDE HANDLE SW
PNK OPEN SW WIRE
PNK WIRE
PPL
PPL MOTOR OPEN OUT
RED WIRE
RIGHT END OF DASH)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Power liftgate circuit, without intelligent key unit -> RIGHT END OF DASH)
Wiring diagram right end of dash) (23 of 26)
1 2 3 4 5 6 7 8 B+
1 2 3 6 7 8 9 10 11 12 13 14 15 16 B+
12 13 14 STR SW A UP STR SW B DWN STR SW C GND
23 24 RH RR CH 4 IN (-) RH RR CH 4 IN (+)
25 26 LH RR CH 3 IN (-) LH RR CH 3 IN (+)
29 30 LH FR CH 1 IN (-) LH FR CH 1 IN (+)
A/C, AV SWITCH
AUDIO UNIT
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BOSE SPEAKER AMPLIFIER (RIGHT REAR OF LUGGAGE COMPT)
BRN WIRE
CAN-H- CAN-L-
COMPUTER DATA LINES SYSTEM
DATA (-) GND
DISPLAY UNIT
EARTH
FUSE 12
FUSE 17
FUSE 32
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
ILL ILL CONT GND BUS+ SHIELD BUS-
LH FR SP (-) LH FR SP (+) RH FR SP (-) RH FR SP (+) ANT SIG BAT (BACK-UP)
LT GRN WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/ WIRE
PNK CONTROL (SWB +) WIRE
PNK WIRE
PPL RH FR CH 2 IN (-) RH FR CH 2 IN (+)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT END OF DASH)
UNIFIED METER, A/C AMP (BEHIND CENTER CONSOLE)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDOW ANTENNA
YEL WIRE
Go to component -> Premium sound radio circuit, without navigation (1 of 2) -> RIGHT END OF DASH)
Wiring diagram right end of dash) (24 of 26)
A/T DEVICE (UNDER FRONT OF CENTER
BLK WIRE
CONSOLE)
DEPRESSED
DETENTION SWITCH
DIODE (LEFT SIDE OF DASH)
DOOR LOCKS SYSTEM
FUSE 12
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRN/RED (OR GRN) WIRE
GRN/RED WIRE
HOT IN ON OR START
J/C 1 (EARLY PRODUCTION) (LEFT SIDE OF DASH)
ORG/ WIRE
RED/YEL WIRE
RELEASED
RIGHT END OF DASH)
SHIFT LOCK SOLENOID
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
W/ INTELLIGENT KEY W/O INTELLIGENT KEY
Go to component -> Shift interlock circuit -> RIGHT END OF DASH)
Wiring diagram right end of dash) (25 of 26)
44 37 38 9 43 10 33 41 29 42 30 34 GND SAT LH + SAT LH - PNK WIRE
AIR BAG
AIR BAG DIAGNOSIS SENSOR UNIT (UNDER REAR OF CENTER CONSOLE)
AIR BAG W/L
BLK WIRE
BLU WIRE
CLH - SLH -
COMBINATION METER
CRH + SEAT BELT SWITCH SRH +
DATA LINK CONNECTOR (PARTIAL) (LOWER LEFT SIDE OF DASH) PPL
FUSE 13
FUSE 14
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GROUND K-LINE ECZS + PPL
HOT IN ON OR START
IGNITION
LEFT FRONT SEAT BELT PRE- TENSIONER (LEFT "B" PILLAR)
LEFT FRONT SIDE AIR BAG MODULE (UNDER DRIVER'S SEAT)
LEFT SIDE AIR BAG (SATELLITE) SENSOR (BASE OF LEFT "B" PILLAR)
LEFT SIDE CURTAIN AIR BAG MODULE (AT LEFT "C" PILLAR)
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RED/BLU WIRE
RIGHT END OF DASH)
RIGHT FRONT SEAT BELT PRE- TENSIONER (RIGHT "B" PILLAR)
RIGHT FRONT SIDE AIR BAG MODULE (UNDER FRONT PASSENGER SEAT)
RIGHT SIDE AIR BAG (SATELLITE) SENSOR (BASE OF RIGHT "B" PILLAR)
RIGHT SIDE CURTAIN AIR BAG MODULE (AT RIGHT C-PILLAR)
SAT RH - SAT RH + GND SRH - CRH -
SLH + SEAT BELT SWITCH CLH + PPL
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> RIGHT END OF DASH)
Wiring diagram right end of dash) (26 of 26)
1 11 9 19 CAN-H CAN-L TX (COMB METER) RX (COMB METER)
25 26 CAN-H CAN-L
29 30 21 22 GND (POWER) GND BATT IGN
ANT INPUT
ANTENNA
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN/WHT WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH)
DIAG-ID INPUT CAN-H
DISPLAY CONTROL UNIT (RIGHT SIDE OF DASH)
FUSE 1
FUSE 12
FUSE 14
FUSE 19
FUSE 22
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE FUSIBLE LINK M LINK BLOCK (RIGHT REAR OF ENGINE COMPARTMENT)
GND CAN-L HAZARD
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD SW
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IGN
LOW TIRE PRESSURE WARNING CONTROL UNIT (RIGHT SIDE OF DASH)
LT GRN WIRE
LT GRN/RED WIRE
NCA WIRE
PPL
RED WIRE
RED/WHT WIRE
RIGHT END OF DASH)
TIRE PRESSURE IND
TIRE PRESSURE SENSOR
TIRE PRESSURE WARNING CHECK SWITCH
UNIFIED METER CONTROL UNIT
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE)
WHT WIRE
WHT/BLU WIRE
Go to component -> Tire pressure monitoring circuit -> RIGHT END OF DASH)
