Infiniti FX45 I (2002-2006) fuse, fusible link block fuse 33 Wiring diagram
This page shows the only wiring diagram for the component.fuse, fusible link block fuse 33, which is found in the car Infiniti FX45 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse, fusible link block fuse 33 (1 of 1)
ALTERNATOR
BATTERY
BLK WIRE
CHARGE INDICATOR
COMBINATION METER
FUSE 14
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK FUSE 33
FUSIBLE LINK A
FUSIBLE LINK HOLDER (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
ORG/ WIRE
RED WIRE
WHT WIRE
Go to component -> Charging circuit -> FUSE, FUSIBLE LINK BLOCK FUSE 33
