Infiniti FX45 I (2002-2006) drv 1 ss drv 1 gnd drv 1 sig Wiring diagram
This page shows the only wiring diagram for the component.drv 1 ss drv 1 gnd drv 1 sig, which is found in the car Infiniti FX45 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv 1 ss drv 1 gnd drv 1 sig (1 of 1)
2 3 PPL
4 5 PPL
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (LEFT REAR OF ENGINE COMPT)
ABS IND.
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE IND
BRN WIRE
CAN 1-H
CAN 1-L GND V
CAN 2 H
CLUS GND CAN 2-L
CLUS SP
COMBINATION METER
DRV 1 SS DRV 1 GND DRV 1 SIG
E/S BAT FR (-) FR (+)
FL (+) FL (-) GND P
FL IN SOL
FL OUT SOL
FR IN SOL
FR OUT SOL
FUSE 14
FUSE 19
FUSE 20
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE ASSEMBLY)
LEFT REAR WHEEL SENSOR (ON LEFT REAR WHEEL HUB ASSEMBLY)
LIS
LT GRN WIRE
MOT (+) MOT (-)
MOT BAT DIAG K
PNK WIRE
PPL
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SENSOR (ON RIGHT FRONT STEERING KNUCKLE ASSEMBLY)
RIGHT REAR WHEEL SENSOR (ON RIGHT REAR WHEEL HUB ASSEMBLY)
RL IN SOL
RL OUT SOL
RL- RL+
RR IN SOL
RR OUT SOL
SLIP IND
UNIFIED METER CONTROL UNIT
VDC OFF BRL RR (-) RR +
VDC OFF IND
VDC/TCS/ABS CONTROL UNIT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> DRV 1 SS DRV 1 GND DRV 1 SIG
