Infiniti FX45 I (2002-2006) change over switch Wiring diagram
This page shows the only wiring diagram for the component.change over switch, which is found in the car Infiniti FX45 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram change over switch (1 of 1)
BLK WIRE
BLU WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
DOOR MIRROR REMOTE CONTROL SWITCH
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
LEFT DOOR MIRROR (FRONT OF DRIVER DOOR)
LEFT/RIGHT MOTOR
LT GRN WIRE
MIRROR SWITCH
OFF
OFF OFF
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT DOOR MIRROR (FRONT OF FRONT PASSENGER DOOR)
UP/DOWN MOTOR
UP/DOWN MOTOR LEFT/RIGHT MOTOR
WHT WIRE
Go to component -> Power mirrors circuit -> CHANGE OVER SWITCH
