Infiniti FX45 I (2002-2006) body computer system Wiring diagrams
This page contains all the electrical diagrams for the component. body computer system, in which he is found in the car Infiniti FX45 I (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram body computer system (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 GND BAT BAT GND
66 67 GPS SIG GPS ANT GND
8 P/R
AUDIO UNIT
BACK-UP
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BODY COMPUTER SYSTEM
BOSE SPEAKER AMPLIFIER (RIGHT REAR OF LUGGAGE COMPARTMENT)
BRN WIRE
CAN L
CAN-H
COMPUTER DATA
DATA (-) GND
EARTH
FR LH SPK +
FR SP LH (-)
FUSE 12
FUSE 17
FUSE 32
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 6
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPARTMENT)
GPS ANTENNA
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IGN
INTERIOR LIGHTS SYSTEM ILL CONT
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT SPEAKER (RIGHT SIDE OF LUGGAGE COMPARTMENT)
LINES SYSTEM
LT GRN WIRE
LT GRN/RED WIRE
NAVI CONTROL UNIT (UNDER FRONT PASSENGER SEAT)
NAVI GND
NAVI INPUT +
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/GRN WIRE
RGB SYNC RGB SHIELD
RX (DCU-AUD)
SHIELD BUS + BUS -
SOUND SYSTEMS
SYNC SHIELD
TX (AUD-DCU)
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE)
VOICE + VOICE - SHIELD PPL
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Navigation circuit, with bose system (1 of 2) -> BODY COMPUTER SYSTEM
Wiring diagram body computer system (2 of 2)
