Infiniti FX45 I (2002-2006) 70 59 rr mtr out rr auto stop Wiring diagram
This page shows the only wiring diagram for the component.70 59 rr mtr out rr auto stop, which is found in the car Infiniti FX45 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 70 59 rr mtr out rr auto stop (1 of 1)
55 42 52 49 BAT BAT GND GND
70 59 RR MTR OUT RR AUTO STOP
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT
BRN WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 22
FUSE 84
FUSE BLOCK (J/B) FUSE 1 (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK M
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
KICK PANEL)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MOVE
ORG/ WIRE
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
PPL/WHT WIRE
REAR WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT)
REAR WIPER MOTOR (CENTER OF BACK DOOR)
RED WIRE
RR MTR -
STOP
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Rear washer/wiper circuit -> 70 59 RR MTR OUT RR AUTO STOP
