Infiniti FX35 II facelift (2011-2013) shift p pass request sw drv request sw rly cont keyless pwr Wiring diagram

1 2 BAT (F/L) PWR WINDOW SPLY (BAT) POWER WINDOWS, SEATS, POWER TOPS SYSTEMS 20 21 22 23 24 25 26 27 28 29 30 31 PPL EXTERIOR LIGHTS SYSTEM RR TURN SIG ACC IND POWER DISTRIBUTION SYSTEM ACC RLY CONT A/T SHIFT AIR CONDITIONING SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS ANTI-THEFT SYSTEM BACK DOOR ANT- BACK DOOR ANT+ DOOR LOCKS, ANTI-THEFT SYSTEMS BCM (BODY CONTROL MODULE) (RIGHT END OF DASH) BLK WIRE BLU WIRE BRN WIRE COMBI IN 1 COMBI IN 4 COMBI IN 2 HAZARD SW COMBI IN 5 COMBI IN 3 PPL COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS DEFOGGER SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS PPL DOOR LOCKS, HEADLIGHTS, ANTI-THEFT SYSTEMS DR SW (DRV) REAR DEF OUT EXTERIOR LIGHTS SYSTEM WIPER/WASHER SYSTEM LR TURN SIG REAR WIPER OUT PNK WIRE FUSE 7 GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HEADLIGHTS, INTERIOR LIGHTS, EXTERIOR LIGHTS SYSTEMS HOT AT ALL TIMES HOT AT ALL TIMES FUSE BLOCK FUSE 10 (J/B) (LEFT KICK PANEL) IGN F/B PASS DR SW IGN RELAY IPDM E/R DOOR LOCKS, ANTI-THEFT SYSTEMS IMMO ANT CTRL IMMO ANT SIG IGN RLY CONT KEYLESS ENTRY KEY SLOT SW LOCK IND LT BLU WIRE LT GRN WIRE MEMORY SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS PASS DOOR ANT- PASS DOOR ANT+ DRV DOOR ANT- DRV DOOR ANT+ PNK CAN-L CAN-H KEY SLOT ILL ON IND WIRE PNK STOP LAMP SW 2 DR UNLOCK SENS WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS POWER DISTRIBUTION SYSTEM MEMORY SYSTEMS POWER WINDOWS SYSTEM PPL PUSH BUTTON IGNITION SWITCH PUSH SW BACK DOOR REQUEST SW TRUNK, TAILGATE, FUEL DOORS SYSTEM PWR WND SW RED WIRE RF TURN SIG LF TURN SIG ROOM LAMP TIMER EXTERIOR LIGHTS SYSTEM SENS GND LIGHT SENS PWR SHIFT P PASS REQUEST SW DRV REQUEST SW RLY CONT KEYLESS PWR STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM STARTER RLY CONT TAN WIRE WARNING, EXTERIOR LIGHTS SYSTEMS WHT WIRE WIPER/WASHER SYSTEM HEADLIGHTS SYSTEM YEL WIRE
