Infiniti FX35 II facelift (2011-2013) deflate cushion side inflate Wiring diagram
This page shows the only wiring diagram for the component.deflate cushion side inflate, which is found in the car Infiniti FX35 II facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram deflate cushion side inflate (1 of 1)
A/T SHIFT SELECTOR (DETENTION SWITCH)
BACK- WARD
BACKWARD
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT BREAKER
CUSHION SIDE DEFLATE SOLENOID
CUSHION SIDE INFLATE SOLENOID
DEFLATE CUSHION SIDE INFLATE
DEFLATE SEAT BACK SIDE
DRIVER SIDE FRONT SEAT
FOR- WARD
FORWARD/
GRN WIRE
GRY WIRE
IND 2 MEMORY
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT
MEMORY 1 SWITCH
MEMORY 2 SET SWITCH SWITCH
MEMORY IND 1
MIRROR CHANGE OVER SWITCH SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
MOTOR
OFF OFF OFF
ON ON ON
OPEN/CLOSE SWITCH
ORG/ WIRE
PNK WIRE
PPL
PPL PNK WIRE
PUMP
PUMP RELAY
RED WIRE
RIGHT
SEAT BACK SIDE DEFLATE SOLENOID
SEAT BACK SIDE INFLATE SOLENOID
SEAT MEMORY SWITCH
SIDE SUPPORT SWITCH INFLATE
SIDE SUPPORT UNIT
SWITCH
TAN WIRE
UP DN LEFT
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (2 of 3) -> DEFLATE CUSHION SIDE INFLATE
