Infiniti FX35 II facelift (2011-2013) 2 3 24 25 comm sig comm sig comm sig comm sig Wiring diagram
This page shows the only wiring diagram for the component.2 3 24 25 comm sig comm sig comm sig comm sig, which is found in the car Infiniti FX35 II facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 3 24 25 comm sig comm sig comm sig comm sig (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 IGN
2 3 24 25 COMM SIG COMM SIG COMM SIG COMM SIG
27 7 14 34 COMM SIG COMM SIG COMM SIG COMM SIG
56 72 CAN-H CAN-L PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER OUTPUT FCW, LDW ON IND CAN-L GND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 3
FUSE BLOCK (J/B) (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT IN ON OR START
ILL
IND
LANE CAMERA UNIT (CENTER FRONT OF ROOF)
LANE DEPARTURE WARNING BUZZER (LOWER CENTER OF DASH)
LDP
LT BLU WIRE
LT GRN WIRE
OFF
PNK WIRE
PPL
PPL LDW SW INPUT CAN-H
RED WIRE
UNIFIED METER, A/C AMPLIFIER (CENTER OF DASH)
WARNING SYSTEMS SWITCH
YEL WIRE
Go to component -> Lane departure warning circuit -> 2 3 24 25 COMM SIG COMM SIG COMM SIG COMM SIG
