Infiniti FX35 II (2008-2011) Climate control seats circuit

16 21 6 PNK WIRE 6 21 16 PNK WIRE 70 35 36 PPL BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRN WIRE CLIMATE CONTROLLED SEAT RELAY (CENTER OF DASH) CONTROLLED SEAT BLOWER MOTOR COOL IND DRIVER SIDE CLIMATE CONTROLLED SEAT BLOWER MOTOR DRIVER SIDE CLIMATE CONTROLLED SEAT CONTROL UNIT DRIVER SIDE CLIMATE CONTROLLED SEAT SWITCH DRIVER SIDE FRONT SEAT DRIVER SIDE SEAT BACK THERMAL ELECTRIC DEVICE DRIVER SIDE SEAT CUSHION THERMAL ELECTRIC DEVICE FUSE 62 FUSE 63 FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HEAT COOL HEAT IND HI MID LO HEAT OFF COOL LO MID HI HOT AT ALL TIMES HOT IN ON OR START FUSE FUSE 3 BLOCK (J/B) (LEFT KICK PANEL) ILLUMINATION LO HI MID LT BLU WIRE LT GRN WIRE MID LO OFF ORG/ WIRE PASSENGER SIDE CLIMATE PASSENGER SIDE CLIMATE CONTROLLED SEAT CONTROL UNIT PASSENGER SIDE CLIMATE CONTROLLED SEAT SWITCH PASSENGER SIDE FRONT SEAT PASSENGER SIDE SEAT BACK PASSENGER SIDE SEAT CUSHION PNK 1 3 WIRE PNK WIRE PPL RED WIRE RED/WHT WIRE TED THERMAL ELECTRIC DEVICE WHT WIRE YEL WIRE YEL/RED WIRE
