Infiniti FX35 II (2008-2011) Cooling fan circuit

1 2 3 PPL 114 113 111 105 116 PNK WIRE 71 84 TW AVCC-PDPRES PDPRES GNDA-PDPRES BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 COOLING FAN RELAY 1 (RIGHT REAR OF ENGINE COMPT) ENGINE CONTROL MODULE (ECM) (RIGHT END OF DASH) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR FUSE 42 FUSIBLE LINK HOLDER (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK O GRN WIRE HOT AT ALL TIMES IGNITION RELAY LT BLU WIRE NCA WIRE ORG/ WIRE PNK PPL WIRE RED WIRE REFRIGERANT PRESSURE SENSOR (CENTER FRONT OF ENGINE COMPT) WHT WIRE YEL WIRE
