Infiniti FX35 II (2008-2011) spd vehicle Wiring diagrams

AV COMM (H) AV COMM (L) AV COMM (H) AV COMM (L) CAN H CAN L AV CONTROL UNIT (BEHIND LEFT SIDE OF DASH) BACK SWITCH BATTERY BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CTRL SIG 1 CTRL SIG 2 CTRL SIG 3 CHANGE SIG DOWN ENTER SWITCH FUSE 19 FUSE 3 (LEFT KICK PANEL) FUSE 34 FUSE 8 FUSE BLOCK (J/B) FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START IGN PRK BRAKE RV SPEED PPL INSTRUMENT CLUSTER SYSTEM EXTERIOR LIGHTS SYSTEM LT BLU WIRE LT GRN WIRE MIC GND MIC SIG MIC VCC MIC GND MIC SIG MICROPHONE MIS VCC NCA WIRE ORG/ WIRE PNK WIRE PPL PUSH RED WIRE SPD VEHICLE STEERING SWITCH SWITCH SWITCH MENU SWITCH SOURCE SWITCH TO TALK UNIFIED METER, A/C AMPLIFIER (CENTER OF DASH) VOLUME SWITCH VOLUME- WHT WIRE YEL WIRE
