Infiniti FX35 II (2008-2011) seat memory switch Wiring diagram
This page shows the only wiring diagram for the component.seat memory switch, which is found in the car Infiniti FX35 II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat memory switch (1 of 1)
1 2 PPL
A/T SHIFT SELECTOR (DETENTION SWITCH)
BACK- WARD
BACKWARD
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
DRIVER SIDE FRONT SEAT
FOR- WARD
FORWARD/
GRN WIRE
GRY WIRE
IND 2 MEMORY
LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
MEMORY 2 SET MEMORY 1 SWITCH SWITCH SWITCH
MEMORY IND 1
MIRROR SWITCH
ON ON ON OFF OFF OFF
OPEN/CLOSE SWITCH
ORG/ WIRE
PNK WIRE
PPL
PPL 1 2 3 4 5 6
PPL PNK WIRE
RED WIRE
RIGHT LEFT
SEAT MEMORY SWITCH
UP DN OFF
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (2 of 3) -> SEAT MEMORY SWITCH
