Infiniti FX35 II (2008-2011) park- ing side marker turn Wiring diagram
This page shows the only wiring diagram for the component.park- ing side marker turn, which is found in the car Infiniti FX35 II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park- ing side marker turn (1 of 1)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 50
FUSE 51
FUSE 53 FUSE 52
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT FRONT COMBINATION LAMP
LT GRN WIRE
ORG/ WIRE
PARK- ING SIDE MARKER TURN
PARK- SIDE MARKER ING
PNK WIRE
PPL
RED WIRE
RIGHT FRONT COMBINATION LAMP
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TAIL LAMP RELAY
TURN
WHT WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> PARK- ING SIDE MARKER TURN
