Infiniti FX35 II (2008-2011) immo ant ctrl immo ant sig ign rly cont keyless entry Wiring diagram

1 2 BAT (F/L) PWR WINDOW SPLY (BAT) POWER WINDOWS, SEATS, POWER TOPS SYSTEMS 20 21 22 23 24 25 26 27 28 29 30 31 PPL RR TURN SIG ACC IND ANTI-THEFT SYSTEM BACK DOOR ANT- BACK DOOR ANT+ BACK DOOR REQUEST SW BCM (BODY CONTROL MODULE) (RIGHT END OF DASH) BLK WIRE BLU WIRE BRN WIRE COMBI IN 5 COMBI IN 3 PUSH SW CAN-L CAN-H KEY SLOT ILL ON IND PPL COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS DEFOGGER SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS TRUNK, TAILGATE, FUEL DOORS SYSTEM DOOR LOCKS, HEADLIGHTS, ANTI-THEFT SYSTEMS DR SW (DRV) REAR DEF OUT EXTERIOR LIGHTS SYSTEM WIPER/WASHER SYSTEM FUSE FUSE (LEFT KICK PANEL) GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HEADLIGHTS, INTERIOR LIGHTS, EXTERIOR LIGHTS SYSTEMS HOT AT ALL TIMES HOT AT ALL TIMES FUSE BLOCK (J/B) HOT W/ ACCESSORY RELAY ENERGIZED IGN RELAY IPDM E/R DR OPENER SW IMMO ANT CTRL IMMO ANT SIG IGN RLY CONT KEYLESS ENTRY KEY SLOT SW ACC F/B IGN F/B PASS DR SW PPL LOCK IND LR TURN SIG REAR WIPER OUT LT BLU WIRE LT GRN WIRE MEMORY SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS ORG/ WIRE PASS DOOR ANT- PASS DOOR ANT+ DRV DOOR ANT- DRV DOOR ANT+ PNK STOP LAMP SW 2 DR UNLOCK SENS WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS POWER DISTRIBUTION SYSTEM MEMORY SYSTEMS POWER WINDOWS SYSTEM PPL PUSH BUTTON IGNITION SWITCH PWR WND SW RED WIRE RF TURN SIG LF TURN SIG ROOM LAMP TIMER S/L PWR SPLY COMBI IN 1 COMBI IN 4 COMBI IN 2 HAZARD SW UNIT COMM SENS GND LIGHT SENS PWR STARTER RLY CONT STARTING/CHARGING SYSTEM STOP LAMP SW 1 TRUNK, TAILGATE, FUEL DOORS SYSTEM WARNING, EXTERIOR LIGHTS SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS WHT WIRE WIPER/WASHER SYSTEM HEADLIGHTS SYSTEM WIPER/WASHER SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM YEL WIRE
