Infiniti FX35 II (2008-2011) gnda qa ta Wiring diagram
This page shows the only wiring diagram for the component.gnda qa ta, which is found in the car Infiniti FX35 II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnda qa ta (1 of 1)
AMP-LCD
AMP-METER
ASCD BRAKE SWITCH (W/O ICC) ICC BRAKE SWITCH (W/ ICC) (ON BRAKE PEDAL BRACKET)
ASCDSW FTPRS
AT SNOW SW
BAT PWR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAMSHAFT BATTERY POSITION CURRENT SENSOR SENSOR (PHASE) (BANK 1)
CAN L
CDCV BRAKE GND GND VBR BNC SW GND GND PNK WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DATA LINK CONNECTOR (LEFT SIDE OF DASH)
EVAP CONTROL SYSTEM PRESSURE SENSOR
FUEL LVL
FUSE
FUSE 7
GNDA PDPRESS KLINE
GNDA QA TA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START FUSE 3 BLOCK FUSE 6 (J/B) (LEFT KICK PANEL)
IGN PWR
INJ 3 INJ 6 TA+2 PPL
KNOCK SENSOR BANK 1
KNOCK SENSOR BANK 2
LCD-AMP
LT BLU WIRE
LT GRN WIRE
METER-AMP
NCA WIRE
ORG/ WIRE
PDPRESS TF AVCC FTPRS GNDA ASCD NEUT H TACHO AVCC PDPRESS GND A
PNK PNK WIRE
PNK WIRE
PPL
PPL PNK WIRE
RED WIRE
SENSOR 2 SENSOR 1 ACCELERATOR PEDAL POSITION SENSOR
TW GND A
W/ ICC W/O ICC
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (4 of 4) -> GNDA QA TA
