Infiniti FX35 II (2008-2011) front passenger side power window switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger side power window switch, which is found in the car Infiniti FX35 II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger side power window switch (1 of 1)
2 1 PPL
BLK WIRE
BLU WIRE
DOWN
ENCODER
FRONT PASSENGER SIDE POWER WINDOW MOTOR (CENTER OF FRONT PASSENGER'S DOOR)
FRONT PASSENGER SIDE POWER WINDOW SWITCH
GRN WIRE
GRY WIRE
ILL
LEFT REAR POWER WINDOW MOTOR (CENTER OF LEFT REAR DOOR)
LEFT REAR POWER WINDOW SWITCH
LT GRN WIRE
MODULE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT REAR POWER WINDOW MOTOR (CENTER OF RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, with driver side anti-pinch system (2 of 2) -> FRONT PASSENGER SIDE POWER WINDOW SWITCH
