Infiniti FX35 II (2008-2011) 3 2 meter amp meter meter meter amp Wiring diagram
This page shows the only wiring diagram for the component.3 2 meter amp meter meter meter amp, which is found in the car Infiniti FX35 II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 2 meter amp meter meter meter amp (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 AWD SOL (+) AWD SOL (-) OIL TEMP (-)
3 2 METER AMP METER METER METER AMP
3.5L
5.0L PNK WIRE
55 71 GND GND
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (LEFT REAR OF ENGINE COMPT)
AWD CONTROL UNIT (RIGHT END OF DASH)
AWD SOLENOID
BAT PWR SPLY
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER (AWD)
COMM (AMP-METER)
COMM (METER-AMP)
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (RIGHT END OF DASH)
FUSE 11
FUSE 3
FUSE 33
FUSE 6
FUSE BLOCK (J/B) (LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN CAN-H AWD SOL BAT GND GND
IGN PWR SPLY
LT GRN WIRE
OIL TEMP +
ORG/ WIRE
PNK CAN-L WIRE
PNK WIRE
UNIFIED METER, A/C AMPLIFIER
VB CAN-L PNK WIRE
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> 3 2 METER AMP METER METER METER AMP
