Infiniti FX35 II (2008-2011) 1 2 3 4 5 6 ign comm-h can-h gnd comm-l can-l Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 BATT BATT 1 2 3 4 5 6 IGN COMM-H CAN-H GND COMM-L CAN-L BLK WIRE BLU WIRE BOOSTER SOLENOID BRAKE BOOSTER (LEFT REAR CORNER OF ENGINE COMPT) BRAKE BOOSTER CONTROL UNIT (RIGHT SIDE OF LUGGAGE COMPT) BRAKE PRESSURE SENSOR (LEFT END (LEFT REAR OF DASH) OF ENGINE COMPT) BRN WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ITS COMM-H RELEASE SW PPL FUSE FUSE 45 FUSE 50 GND DRIVE SIG GND GND CHIME SIG RELEASE SW GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) HOT IN ON OR START IBA OFF SW IBA OFF SWITCH ICC BRAKE HOLD RELAY (IN FUSE, FUSIBLE LINK BLOCK) ICC BRAKE SWITCH (ON BRAKE PEDAL BRACKET) ICC WARNING CHIME (LEFT END OF DASH) IGN LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK COMPUTER DATA LINES SYSTEM ITS COMM-L RELEASE SW WIRE PNK COMPUTER DATA LINES SYSTEM WIRE PNK WIRE PPL RED WIRE RELEASE SWITCH SEN GND SEN PWR SEN SIG SOL GND SOL PWR WHT WIRE YEL WIRE
