Car Wiring Diagrams for Charging circuit for Infiniti FX35 I (2002-2006)

ALTERNATOR BATTERY BLK WIRE CHARGE INDICATOR COMBINATION METER FUSE 14 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK FUSE 33 FUSIBLE LINK A FUSIBLE LINK HOLDER (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START LT GRN WIRE ORG/ WIRE RED WIRE WHT WIRE
