Infiniti FX35 I (2002-2006) washer indicator Wiring diagram
This page shows the only wiring diagram for the component.washer indicator, which is found in the car Infiniti FX35 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram washer indicator (1 of 1)
55 42 52 49 BAT BAT GND GND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FR MTR
FRONT WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT) (BEHIND INSTRUMENT CLUSTER)
FRONT WIPER HI RELAY
FRONT WIPER MOTOR (LEFT SIDE OF FIREWALL)
FRONT WIPER RELAY
FUSE 1
FUSE 14
FUSE 22
FUSE 73
FUSE 78 FUSE 71
FUSE 84
FUSE BLOCK (J/B) (BEHIND
FUSE, FUSIBLE
FUSIBLE LINK M
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
HIGH PPL
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
JOINT CONNECTOR 2 (EARLY PRODUCTION) (LEFT SIDE OF DASH)
KICK PANEL)
LINK BOX (RIGHT REAR OF ENGINE COMPT)
LOW PNK WIRE
LT BLU WIRE
MOVE
ORG/ WIRE
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
STOP
WASHER INDICATOR
WASHER LEVEL SENSOR (LOWER RIGHT FRONT OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Front wiper/washer circuit -> WASHER INDICATOR
