Infiniti FX35 I (2002-2006) w/ intelligent key w/o intelligent key Wiring diagrams
This page contains all the electrical diagrams for the component. w/ intelligent key w/o intelligent key, in which he is found in the car Infiniti FX35 I (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ intelligent key w/o intelligent key (1 of 2)
ABS IND.
AIR BAG IND
AWD IND
BELT IND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT)
BRAKE IND
BUZZER
CHARGE IND
CLOCK
COMBINATION METER
CRUISE IND
DOOR IND
FUEL GAUGE TACHOMETER
FUEL IND
FUSE 14
FUSE 22
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) FUSE 38
GRN/YEL WIRE
GRY WIRE
HEADLAMP AIMING SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM CONTROL SWITCH ILLUM
INSERTED
JOINT CONNECTOR 2 (EARLY PRODUCTION) (LEFT SIDE OF DASH)
KEY IND (GREEN) METER ILLUM (2)
KEY SWITCH
KEY SWITCH WITHDRAWN
KEY SWITCH, IGNITION KNOB SWITCH PUSHED IGNITION KNOB SWITCH
LEFT TURN IND
LT GRN WIRE
LT GRN/RED WIRE
METER SIDE SWITCH
NCA WIRE
ODO/TRIP METER ILLUM
ODO/TRIP METER SWITCH
OIL IND
P-SHIFT IND
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PPL
PPL 4 5 6 7
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
REMOVED
RIGHT TURN IND
SLIP IND
SNOW IND
SPEEDO- METER
STARTING/CHARGING SYSTEM HEADLIGHTS SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TIRE PRESSURE IND
TRIP RESET
TRIP TRANSFER
UNIFIED METER CONTROL UNIT
VDC OFF IND
W/ INTELLIGENT KEY
W/ INTELLIGENT KEY ONLY KEY IND
W/ INTELLIGENT KEY W/O INTELLIGENT KEY
W/O INTELLIGENT KEY
WARNING SYSTEM
WASHER IND
WATER TEMP GAUGE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WIPER/WASHER SYSTEM
Go to component -> Gauges & indicators circuit (1 of 2) -> W/ INTELLIGENT KEY W/O INTELLIGENT KEY
Wiring diagram w/ intelligent key w/o intelligent key (2 of 2)
A/T DEVICE (UNDER FRONT OF CENTER
BLK WIRE
CONSOLE)
DEPRESSED
DETENTION SWITCH
DIODE (LEFT SIDE OF DASH)
DOOR LOCKS SYSTEM
FUSE 12
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRN/RED (OR GRN) WIRE
GRN/RED WIRE
HOT IN ON OR START
J/C 1 (EARLY PRODUCTION) (LEFT SIDE OF DASH)
ORG/ WIRE
RED/YEL WIRE
RELEASED
RIGHT END OF DASH)
SHIFT LOCK SOLENOID
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
W/ INTELLIGENT KEY W/O INTELLIGENT KEY
Go to component -> Shift interlock circuit -> W/ INTELLIGENT KEY W/O INTELLIGENT KEY
