Infiniti FX35 I (2002-2006) transmissions, exterior lights, navigation systems Wiring diagram
This page shows the only wiring diagram for the component.transmissions, exterior lights, navigation systems, which is found in the car Infiniti FX35 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmissions, exterior lights, navigation systems (1 of 1)
A/C RELAY
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM
FROM FUSE 73 (DIAGRAM 1 OF 3)
FROM FUSIBLE LINK E (DIAGRAM 1 OF 3)
FROM FUSIBLE LINK F (DIAGRAM 1 OF 3)
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE 1
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 78 FUSE 80
FUSE 79
FUSE 81
FUSE 82
FUSE 83 FUSE 84
FUSE 85 FUSE 89
FUSE 9
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
IGNITION RELAY
IGNITION SWITCH
LT BLU WIRE
LT GRN WIRE
MIRRORS, SEATS SYSTEMS
ON LOCK OFF
ORG/ WIRE
PNK PPL WIRE
PNK WIRE
PPL
RED WIRE
SEATS SYSTEM
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO ACCESSORY RELAY 2 (DIAGRAM 3 OF 3)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, ENGINE CONTROLS SYSTEMS
TRANSMISSIONS, EXTERIOR LIGHTS, NAVIGATION SYSTEMS
WHT WIRE
WIPER/ WASHER SYSTEM
WIPER/ WASHER SYSTEM WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> TRANSMISSIONS, EXTERIOR LIGHTS, NAVIGATION SYSTEMS
