Infiniti FX35 I (2002-2006) sliding switch reclining switch Wiring diagram
This page shows the only wiring diagram for the component.sliding switch reclining switch, which is found in the car Infiniti FX35 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sliding switch reclining switch (1 of 1)
BK FD
BLK WIRE
BLU WIRE
CIRCUIT BREAKER (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE FRONT POWER SEAT
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK M
GRN WIRE
HOT AT ALL TIMES
LIFTING MOTOR (FRONT) LIFTING MOTOR (REAR)
LIFTING SWITCH (FRONT) LIFTING SWITCH (REAR)
PASSENGER SIDE FRONT POWER SEAT
PNK WIRE
POWER SEAT SWITCH
RECLINING MOTOR
RECLINING SWITCH
RED WIRE
SLIDING MOTOR
SLIDING MOTOR RECLINING MOTOR
SLIDING SWITCH
SLIDING SWITCH RECLINING SWITCH
UP DN UP
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power seats circuit -> SLIDING SWITCH RECLINING SWITCH
