Infiniti FX35 I (2002-2006) open switch close switch door switch half latch switch Wiring diagram
This page shows the only wiring diagram for the component.open switch close switch door switch half latch switch, which is found in the car Infiniti FX35 I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open switch close switch door switch half latch switch (1 of 1)
BACK DOOR CLOSURE CONTROL UNIT (LOWER LEFT SIDE OF BACK DOOR)
BACK DOOR CLOSURE MOTOR (LOWER CENTER OF BACK DOOR)
BACK DOOR OPEN OUTPUT
BACK DOOR OPENER SWITCH
BLK WIRE
BLU WIRE
DOOR LOCKS SYSTEM
FUSE 18
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
INTELLIGENT KEY UNIT (LEFT END OF DASH)
LT GRN WIRE
OFF
ON OFF OFF OFF
ON ON ON
OPEN SWITCH CLOSE SWITCH DOOR SWITCH HALF LATCH SWITCH
OPEN/ CLOSE MOTOR
ORG/ WIRE
PNK BACK DOOR OPEN SWITCH WIRE
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
YEL WIRE
Go to component -> Power liftgate circuit, with intelligent key unit -> OPEN SWITCH CLOSE SWITCH DOOR SWITCH HALF LATCH SWITCH
