Electronic power steering circuit for Infiniti EX35 I (2007-2013)

1 2 3 4 5 6 7 8 9 10 11 12 EPS SOL+ BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENG TACHO ENGINE CONTROL MODULE (ECM) (RIGHT END OF DASH) EPS SOL GND FUSE 45 GRN WIRE HOT IN ON OR START IGN LT GRN WIRE POWER STEERING CONTROL UNIT (RIGHT SIDE OF DASH) POWER STEERING SOLENOID VALVE RED WIRE TACHO UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE) VEHICLE SPEED 56 72 CAN-H CAN-L PNK WIRE VSP
