Car Wiring Diagrams for Charging circuit for Hyundai Venue I (2019-2024)

A/V, NAVIGATION HEAD UNIT ALT FUSE ALT L OUT ALTERNATOR AUDIO B-CAN BATTERY BATTERY FUSE BLOCK BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE C-CAN C-CAN HIGH C-CAN LOW CHARGE IND CLUSTER FUSE COMPUTER DATA LINES SYSTEM CVT E/R JUNCTION BLOCK GRY WIRE ICU JUNCTION BLOCK ICU-C INSTRUMENT CLUSTER LIN M/T MICOM MULTI FUSE PCM (CVT) ECM (M/T) RED WIRE RELAY ENERGIZED STARTING CIRCUIT TRANSCEIVER/ W/ NAVIGATION W/O NAVIGATION WHT WIRE
