Exterior lamps circuit for Hyundai Venue I (2019-2024)

AUTO B-CAN HIGH B-CAN LOW B-CAN TRANSCEIVER BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE C-CAN CENTER FACIA SWITCH COMPUTER DATA LINES SYSTEM CORNERING LAMP CORNERING POWER DRIVER POWER OUTSIDE MIRROR GND (BCM) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE HAZARD SW IN HAZARD SWITCH HEAD TAIL (LOW) IBU ILL INSTRUMENT CLUSTER LAMP SW LEFT LEFT CORNERING LAMP LEFT FRONT TURN SIG LAMP OUT LEFT HEADLAMP LEFT REAR TURN SIG LAMP OUT LEFT SIDE REPEATER LAMP LEFT T/SIG ACTUATOR LEFT TURN LAMP LEFT TURN SIG LAMP LIGHT LIGHT SW SIG MICOM NCA WIRE OFF PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RIGHT RIGHT CORNERING LAMP RIGHT FRONT TURN SIG LAMP OUT RIGHT T SIG ACTUATOR RIGHT TURN SIG LAMP SIDE REPEATER LAMP STOP LAMP SIG SW SIG T/ SIGNAL ACTUATOR TAIL LAMP TAIL ON IND TRANSCEIVER/ TURN IND TURN LAMP TURN SIG TURN SIG LAMP SW TURN SIG LAMP SW IN W/ LED W/ SIDE REPEATER W/O LED W/O SIDE REPEATER WHT WIRE WIPER, LIGHT GND YEL WIRE

B+1 FUSE B+2 FUSE BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE CLUSTER FUSE CORNERING LAMP E/R JUNCTION BLOCK GRN WIRE GRN/BLK WIRE GRN/ORG WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START ICU JUNCTION BLOCK ICU-A ICU-B ICU-C IPS CONTROL LEFT LICENSE LAMP LEFT REAR COMBINATION LAMP MODULE 5 FUSE NCA WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RIGHT HEADLAMP RIGHT LICENSE LAMP STOP LAMP T/ SIGNAL ACTUATOR T/SIGNAL LAMP FUSE TAIL LAMP TURN LAMP W/ LED W/O LED WHT WIRE

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BRAKE LIGHT SW BRAKE SWITCH FUSE BRAKE TEST SW BRN WIRE COMPUTER DATA LINES SYSTEM CVT ECM/PCM ESC MODULE GRN/ORG WIRE GRY WIRE HIGH MOUNTED STOP LAMP HOT AT ALL TIMES HOT IN ON OR START ICU JUNCTION BLOCK ICU-A ICU-C IPS CONTROL MODULE M/T MODULE 1 FUSE NCA WIRE PASSENGER POWER OUTSIDE MIRROR PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RIGHT REAR COMBINATION LAMP RIGHT SIDE REPEATER LAMP RIGHT TURN LAMP SIDE REPEATER LAMP STOP LAMP STOP LAMP SIG STOP LAMP SWITCH TAIL LAMP TURN LAMP W/ LED W/ SIDE REPEATER W/O LED W/O SIDE REPEATER
