Hyundai Venue I (2019-2024) tailgate unlock relay ctrl wiring diagram
This page shows the only wiring diagram for the component.tailgate unlock relay ctrl, which is found in the car Hyundai Venue I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
tailgate unlock relay ctrl wiring diagram (1 of 1)
ANTI-LOCK BRAKES SYSTEM
B-CAN CRASH OUTPUT LOW HIGH
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE PARKING OIL BRAKE LEVEL GROUND SENSOR
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCK
DOOR LOCK RELAY
DOOR LOCK/UNLOCK SIG
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR SWITCH
DOOR UNLOCK
DOOR UNLOCK RELAY
DR LOCK FUSE
DRIVER PASSENGER
EXTERIOR, HEADLIGHTS SYSTEMS
FUSE SWITCH
FUSE SWITCH CTRL
GRN WIRE
GRN/BLK WIRE
GROUND SIGNAL 1
GROUND SIGNAL 2
GRY WIRE
HEADLAMP LOW SIGNAL
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-C
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEAK CURRENT AUTO CUT DEVICE RELAY
LH REAR
LUGGAGE LAMP
OFF
OFF ON
ORG/ WIRE
P/WDW LH FUSE
P/WDW RH FUSE
PASSENGER
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER WINDOW RELAY
POWER WINDOW RELAY CTRL
POWER WINDOWS SYSTEM
RED WIRE
RELAY CTRL
RH REAR
SUPPLEMENTAL RESTRAINTS SYSTEM
T/TURN UNLOCK RELAY
T/TURN UNLOCK RELAY CTRL
TAILGATE OPEN TAILGATE SIGNAL SWITCH
TAILGATE UNLOCK RELAY
TAILGATE UNLOCK RELAY CTRL
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Ips control module circuit (1 of 2) -> TAILGATE UNLOCK RELAY CTRL
