Hyundai Venue I (2019-2024) press sensor sensor 1 signal Wiring diagram
This page shows the only wiring diagram for the component.press sensor sensor 1 signal, which is found in the car Hyundai Venue I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram press sensor sensor 1 signal (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
CMPS EXHAUST SIGNAL
ECTS 2 SIGNAL
GRN WIRE
GRY WIRE
GRY/BLK WIRE
IAT SIGNAL
IC IGNITER
IGN COIL 1 CTRL CYL 1 FDBACK
IGN COIL 2 CTRL CYL 2 FDBACK
IGN COIL 3 CTRL CYL 3 FDBACK
IGN COIL 4 CTRL CYL 4 FDBACK
KNOCK SENSOR
KNOCK SENSOR GND
KNOCK SENSOR SIGNAL
ORG/ WIRE
PCM
PNK WIRE
PRESS SENSOR SENSOR 1 SIGNAL
PRESS SENSOR SENSOR 2 SIGNAL
PUMPING CURRENT
RED WIRE
RED/BLK WIRE
SELECT SW
SENSOR 1/2 SUPPLY
SENSOR SIGNAL
SIGNAL
SOLENOID SECONDARY
SOLENOID SUPPLY 1
SOLENOID SUPPLY 2
SUPPLY
TPS I SIGNAL
VEH SPD SENSOR 1 SUPPLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 1.6l, cvt (3 of 7) -> PRESS SENSOR SENSOR 1 SIGNAL
