Hyundai Venue I (2019-2024) current auto cut device rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.current auto cut device rly ctrl, which is found in the car Hyundai Venue I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram current auto cut device rly ctrl (1 of 1)
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
AUDIO
AUTOMATIC A/C
BLK WIRE
BLU WIRE
BRAKE SWITCH FUSE
CURRENT AUTO CUT DEVICE RLY CTRL
DATA LINK CONNECTOR
DRL FUSE
DRL RELAY
FROM E/R JUNCTION BLOCK (DIAGRAM 1 OF 7)
FUSE SWITCH CTRL
GRY WIRE
IBU
IBU 1 FUSE
ICU-A
ICU-B
ICU-C
INSTRUMENT CLUSTER
INTERIOR LAMP FUSE
IPS CONTROL MODULE
KEY INTERLOCK SOLENOID
LEAK
LEAK CURRENT AUTO CUT DEVICE
LEAK CURRENT AUTO CUT DEVICE RELAY
LEAK CURRENT AUTOCUT DEVICE SWITCH
LEFT FRONT VANITY LAMP
LUGGAGE LAMP
MANUAL A/C
MAP LAMP
MEMORY 1 FUSE
MEMORY 2 FUSE
MODULE 6 FUSE
MULTIMEDIA FUSE
OFF ON
ORG/ WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT VANITY LAMP
ROOM LAMP
SRS CONTROL MODULE
STOP LAMP SWITCH
T/SIGNAL LAMP FUSE
W/ MAP LAMP
W/ NAVIGATION
W/ SUNROOF, MTS
W/ SUNROOF, W/O MTS
W/O MAP LAMP
W/O NAVIGATION
W/O SMART KEY
W/O SUNROOF
Go to component -> Power distribution circuit (5 of 7) -> CURRENT AUTO CUT DEVICE RLY CTRL
