Hyundai Veloster II (2018-2024) rear power window switch Wiring diagram
This page shows the only wiring diagram for the component.rear power window switch, which is found in the car Hyundai Veloster II (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear power window switch (1 of 1)
AUTO DOWN
AUTO UP
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LOCK, UNLOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DRIVER WINDOW SWITCH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-C
IGPM
ILL
IPS CONTROL MODULE
LOCK
OFF
OFF DOWN
OFF UP
ORG/ WIRE
P/WINDOW RH FUSE
PASSENGER WINDOW SWITCH
PNK WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOW RH RELAY
REAR POWER WINDOW MOTOR
REAR POWER WINDOW SWITCH
REAR WINDOW SWITCH RH
RED WIRE
RELAY CONTROL
UNLOCK
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power windows circuit, w/ driver auto up/down & safety power windows (1 of 2) -> REAR POWER WINDOW SWITCH
