Hyundai Veloster II (2018-2024) b-can high rear defogger sw input Wiring diagram
This page shows the only wiring diagram for the component.b-can high rear defogger sw input, which is found in the car Hyundai Veloster II (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b-can high rear defogger sw input (1 of 1)
A/C CONTROL MODULE
AUTOMATIC A/C
B-CAN HIGH
B-CAN HIGH REAR DEFOGGER SW INPUT
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DRIVER POWER OUTSIDE MIRROR
E/R JUNCTION BLOCK
ECM (1.6L TURBO)
GATEWAY
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HEATED MIRROR FUSE
HOT AT ALL TIMES
I/P-A
I/P-C
I/P-E
I/P-G
IGPM
IND
IPS CONTROL MODULE
MANUAL A/C
MULTI FUSE 2
NCA WIRE
OFF
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RED/BLK WIRE
RELAY CONTROL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Defoggers circuit, w/o auto defogger -> B-CAN HIGH REAR DEFOGGER SW INPUT
