Hyundai Veloster I facelift (2015-2017) ect sensor signal Wiring diagrams
This page contains all the electrical diagrams for the component. ect sensor signal, in which he is found in the car Hyundai Veloster I facelift (2015-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ect sensor signal (1 of 3)
A/C SWITCH INPUT
A/CON RLY CONTROL
AIR CONDITIONING SYSTEM
AUTOMATIC A/C W/ DUAL CLUTCH W/O DUAL CLUTCH
BLK WIRE
BLOWER SWITCH INPUT
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C/FAN FUSE
COOLING FAN CONTROLLER
COOLING FAN HIGH RELAY
COOLING FAN PWM CONTROL
E/R JUNCTION BLOCK
ECT SENSOR GROUND
ECT SENSOR SIGNAL
ECU 1 FUSE
ENGINE CONTROL RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR, SENDER
ENGINE CTRL RLY CTRL
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
MICOM
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER CONDITIONING
RADIATOR FAN MOTOR
RED WIRE
SENSOR
SENSOR 2 FUSE
SR-
TEMP
THERMO SWITCH
W/ DUAL CLUTCH
WHT WIRE
Go to component -> 1.6l turbo, cooling fan circuit -> ECT SENSOR SIGNAL
Wiring diagram ect sensor signal (2 of 3)
1.6L
1.6L TURBO 1.6L W/O DUAL CLUTCH W/ DUAL CLUTCH
1.6L TURBO W/ DUAL CLUTCH
1.6L W/ DUAL CLUTCH
A/C PRESSURE SW I/P (THERMO SW) A/C SW I/P C-CAN LOW
A/C PRESSURE TRANSDUCER
A/C RELAY CONTROL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HIGH
C/FAN (HI) RLY CTRL
C/FAN (LO) RLY CTRL BLOWER SW I/P
C/FAN FUSE
COMPUTER DATA LINES SYSTEM
COOLING FAN CONTROLLER
COOLING FAN HIGH RELAY
COOLING FAN LOW RELAY
COOLING FAN MOTOR
E/R JUNCTION BLOCK
ECT SENSOR GROUND
ECT SENSOR SIGNAL
ECU 1 FUSE
ENGINE CONTROL
ENGINE CONTROL RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR, SENDER
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
MICOM
NCA WIRE
NOT USED NOT USED
ORG/ WIRE
PNK WIRE
POWER CONDITIONING
RADIATOR FAN MOTOR
RED WIRE
S/R TEMP
SENDER
SENDER GND
SENDER SIGNAL
SENSOR 2 FUSE
SENSOR 3 FUSE
W/ DUAL CLUTCH
WHT WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> ECT SENSOR SIGNAL
Wiring diagram ect sensor signal (3 of 3)
1.6L
1.6L 1.6L TURBO
1.6L TURBO W/ DUAL CLUTCH
1.6L W/ DUAL CLUTCH
A/C COMPRESSOR
A/C PRESSURE TRANSDUCER
A/C SWITCH INPUT
A/CON FUSE
A/CON RELAY
A/CON RLY CTRL
BLK WIRE
BLOWER SWITCH INPUT
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C/FAN (HI) RLY CTRL
C/FAN (LO) RLY CTRL (OR C/FAN PWM CTRL)
C/FAN FUSE
COOLING FAN CONTROLLER
COOLING FAN HIGH RELAY
COOLING FAN LOW RELAY
COOLING FAN MOTOR
E/R JUNCTION BLOCK
ECT SENSOR GROUND
ECT SENSOR SIGNAL
ECU 1 FUSE
ENGINE CONTROL RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE CTRL RLY CTRL
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/ WIRE
PNK 1.6L TURBO WIRE
PNK MICOM WIRE
PNK WIRE
POWER CONDITIONING
RADIATOR FAN MOTOR
RED WIRE
SENSOR 2 FUSE
SENSOR 3 FUSE
SENSOR GROUND
SENSOR SIGNAL
TEMP
THERMO SWITCH
W/ DUAL CLUTCH
WHT WIRE
Go to component -> Manual a/c circuit (2 of 2) -> ECT SENSOR SIGNAL
