Hyundai Veloster I facelift (2015-2017) c-can hi 45 31 c-can lo Wiring diagram
This page shows the only wiring diagram for the component.c-can hi 45 31 c-can lo, which is found in the car Hyundai Veloster I facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram c-can hi 45 31 c-can lo (1 of 1)
1.6L 1.6L TURBO
1.6L TURBO W/ DUAL CLUTCH
1.6L W/ DUAL CLUTCH
A/V, NAVIGATION HEAD UNIT
ABS 2 FUSE
ABS FUSE
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
C-CAN HI
C-CAN HI 45 31 C-CAN LO
C-CAN LO
CCP CAN HI
CCP CAN LO
CONNECTOR
DATA LINK
DATA LINK CONNECTOR (LOWER LEFT END OF DASH)
E/R JUNCTION BLOCK
FLEX RAY HI
FLEX RAY LO
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-C
I/P-D
I/P-H
I/P-N
IMMOBILIZER MODULE
INSTRUMENT CLUSTER
IPS CONTROL MODULE
JOINT CONNECTOR UMA
JOINT CONNECTOR UMB
K LINE
LEAK CURRENT AUTO CUT DEVICE
M-CAN HI
M-CAN LO
MDPS UNIT (BOTTOM OF STEERING COLUMN)
MEMORY FUSE
MTS MODULE
MULTI FUSE
MULTIPURPOSE CHECK CONNECTOR
ORG/ WIRE
PANORAMA SUN ROOF MOTOR
PASSENGER OCCUPANT DETECTION SENSOR
PNK VEH SPD WIRE
PNK WIRE
RED WIRE
SMART JUNCTION BLOCK
SMART KEY CONTROL MODULE
SPORT MODE SWITCH
SRS CONTROL MODULE
STANDARD
TCM
VEH SPD
VERSION 4.0
W/O SMART KEY
Go to component -> Computer data lines circuit (1 of 2) -> C-CAN HI 45 31 C-CAN LO
