Car Wiring Diagrams for Heated seats circuit for Hyundai Veloster I (2011-2015)

BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT WARMER DRIVER SEAT WARMER SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-E I/P-K IG 1 IG 1 FUSE IND IND IND SWITCH GROUND HIGH LOW SIGNAL IND SWITCH GROUND HIGH LOW SIGNAL ORG/ WIRE PASSENGER SEAT WARMER PASSENGER SEAT WARMER SWITCH PNK 27 WIRE PNK WIRE PNK/BLK WIRE RED WIRE S/HEATER FUSE SMART JUNCTION BOX YEL WIRE
