Hyundai Veloster I (2011-2015) thermo switch a/c switch input Wiring diagram
This page shows the only wiring diagram for the component.thermo switch a/c switch input, which is found in the car Hyundai Veloster I (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thermo switch a/c switch input (1 of 1)
20 EGGT-AK 13 82 EGGT-AA COOLING FAN PWM CONTROL
50 EGGT-AK 83 EGGT-AK 30 31 EGGT-AA 55 EGGT-AA ENGINE CTRL RLY CTRL
59 EGGT-MA 24 23 EGGT-MA PNK WIRE
93 EGGT-MK 29 EGGT-MA 44 43 EGGT-MK 39 EGGT-MA
A/CON RELAY CONTROL
A/T
AIR CONDITIONING SYSTEM
BLK WIRE
BLOWER SWITCH INPUT
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C/FAN FUSE
COOLING FAN (HIGH)
COOLING FAN CONTROLLER (LEFT FRONT OF ENGINE COMPT)
ECM (LEFT REAR OF ENGINE COMPT)
ECT SENSOR GROUND ECT SENSOR SIGNAL
ECU 1 FUSE
EGGTCR
ENGINE CONTROL RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR, SENDER (REAR OF ENGINE)
GRN WIRE
HOT AT ALL TIMES
M/T
MICOM
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER CONDITIONING
POWER DISTRIBUTION SYSTEM
RADIATOR FAN MOTOR
RED WIRE
RELAY
SENSOR 2 FUSE
SR-
TEMP
THERMO SWITCH A/C SWITCH INPUT
WHT WIRE
Go to component -> 1.6l turbo, cooling fan circuit -> THERMO SWITCH A/C SWITCH INPUT
