Wiring diagram engine performance 1.6l turbo hybrid, hybrid control circuit for Hyundai Tucson IV (2020-2024)

A/C FUSE B+ INPUT BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/ORG WIRE BUS BAR CLUTCH PRESS SENS GND CLUTCH PRESS SENS PWR CLUTCH PRESS SENS SIG ENGINE CONTROL CIRCUIT GRN WIRE GRN/BLK WIRE HEV RELAY STATUS HIGH VOLTAGE JUNCTION BLOCK HPCU HPCU (RIGHT FRONT OF ENGINE COMPT) HSG TEMP SENS GND HSG TEMP SENS SHIELD HSG TEMP SENS SIG HV-C HV-P HYBRID INVERTER HYBRID MOTOR (LEFT REAR OF ENGINE) HYBRID STARTER, GENERATOR MOTOR INTERLOCK - INTERLOCK SIG MOTOR TEMP SENS GND MOTOR TEMP SENS SHIELD MOTOR TEMP SENS SIG OPU FUSE ORG/ WIRE PNK ON/START INPUT WIRE PNK WIRE POWER U POWER V POWER W RED WIRE RESOLVER RESOLVER SENS 1 RESOLVER SENS 2 RESOLVER SENS 3 RESOLVER SENS 4 RESOLVER SIG SHIELD START SIGNAL STARTING/ CHARGING SYSTEM TEMP SENS GND TEMP SENS SHIELD TEMP SENS SIG TERMINAL BLOCK WAKE UP SIF (MCU) WHT WIRE YEL WIRE

BATTERY MANAGEMENT FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CLUTCH PRESSURE SENSOR COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM E/R JUNCTION BLOCK ELECTRONIC A/C COMPRESSOR GRN WIRE GRY WIRE H-CAN HIGH H-CAN LOW HOT AT ALL TIMES HPCU HPCU (RIGHT FRONT OF ENGINE COMPT) HPCU 1 FUSE HPCU 2 FUSE HSG RESOLVER HSG RESOLVER SENS 1 HSG RESOLVER SENS 2 HSG RESOLVER SENS 3 HSG RESOLVER SENS 4 HSG RESOLVER SHIELD ICU JUNCTION BLOCK ICU-B LDC MOTOR RESOLVER MOTOR RESOLVER SENS 1 MOTOR RESOLVER SENS 2 MOTOR RESOLVER SENS 3 MOTOR RESOLVER SENS 4 MOTOR RESOLVER SHIELD NCA WIRE OPCU FUSE ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PNK WIRE PNK/BLK WIRE PWR RED WIRE RELAY ENERGIZED SERVICE PLUG SIG TCU 2 FUSE TO POWER RELAY ASSEMBLY (DIAGRAM 5 TO 7) WATER PUMP (LIN) WHT WIRE YEL WIRE

B+ INPUT BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BMS BMS ASSEMBLY BMS COOLING FAN, TEMPERATURE SENSOR BRN WIRE C/FAN PWR C/FAN RELAY CTRL COMPUTER COOLING FANS SYSTEM CURRENT SENS GND CURRENT SENS SIG CURRENT SENS VOUT DATA LINES SYSTEM ELECTRONIC OIL PUMP (LOWER RIGHT END OF DASH) EMERGENCY INTLK GND EMERGENCY INTLK SIG GRN WIRE GRY WIRE GRY/ORG WIRE H-CAN HIGH H-CAN LOW MAIN BATTERY MODULE TEMPERATURE SENSOR 2 MAIN BATTERY MODULE TEMPERATURE SENSOR 3 MAIN BATTERY MODULE TEMPERATURE SENSOR 4 MAIN BATTERY TEMPERATURE SENSOR 1 MAIN RELAY ON/START INPUT OPU OPU STATUS ORG/ WIRE P-CAN HI P-CAN LO PNK WIRE POSITION SENS GND POSITION SENS PWR POSITION SENS U POSITION SENS V POSITION SENS W POSITION SIG GND POSITION SIG PWR POSITION SIG U POSITION SIG V POSITION SIG W PRE CHARGE RELAY PUMP PWR INPUT U PUMP PWR INPUT V PUMP PWR INPUT W PWM COMMAND PWR INPUT (+) RED WIRE RED/WHT WIRE RELAY CONTROL OFF RELAY CONTROL ON RELAY SIG SHIELD SPEED TCM TEMP SIG 1 GND TEMP SIG 1 SIG TEMP SIG 2 GND TEMP SIG 2 SIG TEMP SIG 3 GND TEMP SIG 3 SIG TEMP SIG 4 GND TEMP SIG 4 SIG TEMP SIG LV BATT GND TEMP SIG LV BATT SIG TO POWER RELAY ASSEMBLY (DIAGRAM 5 OF 7) VF (FEEDBACK) WHT WIRE YEL WIRE

10.25 INCH TFT LCD 4.2 INCH TFT LCD BLK WIRE BLU WIRE BLU/ORG WIRE BMS WAKE UP C-CAN TRANSCEIVER (10.25 INCH TFT LCD) CHARGE IND CLUSTER FUSE COMPUTER DATA LINES SYSTEM CRASH PAD SWITCH E-CAN TRANSCEIVER (4.2 INCH TFT LCD) GDC POWER BLOCK GRN WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE HI LO HOT W/ PDM HOT W/ PDM (ACC) RELAY ENERGIZED ICU JUNCTION BLOCK ICU-C ICU-D ICU-F ILL INSTRUMENT CLUSTER INTERFACE IPS CONTROL MODULE MICOM MODULE 1 FUSE ORG/ WIRE PNK WIRE PNK/BLK WIRE RED WIRE RELAY ENERGIZED TFT LCD (10.25) TFT LCD DRIVE WHT WIRE

ACC/ON INPUT B+ INPUT BLK WIRE BLK/BLU WIRE BLU WIRE BLU/WHT WIRE BMS BMS ASSEMBLY BMS B+ FUSE BRN WIRE COMPUTER DATA LINES SYSTEM CRASH SIG CURRENT SENS GND CURRENT SENS VC (HV) CURRENT SENS VOUT CURRENT SENSOR CURRENT SENSOR (LV) FROM BMS (DIAGRAM 3 OF 7) FROM E/R JUNCTION BLOCK (DIAGRAM 2 TO 7) FUSE G-CAN HIGH G-CAN LOW GRN WIRE GRN/ORG WIRE GRY WIRE H-CAN HIGH H-CAN LOW ICU POWER MAIN NEGATIVE RELAY MAIN POSITIVE RELAY NEG RELAY TEMPERATURE SENSOR ORG/ WIRE PNK WIRE PNK/BLK WIRE POS RELAY TEMPERATURE SENSOR POWER RELAY ASSEMBLY PRE CHARGE RELAY PRE-CHARGE RESISTOR RED WIRE RED/WHT WIRE RELAY S/W FUSE SUPPLEMENTAL RESTRAINTS SYSTEM TO MAIN BATTERY MODULE 1 (DIAGRAM 6 OF 7) TO MAIN BATTERY MODULE 9 (DIAGRAM 7 OF 7) WHT WIRE YEL WIRE YEL/WHT WIRE

*** BLU WIRE BMS BMS ASSEMBLY BRN WIRE BUS BAR FROM BMS (DIAGRAM 7 OF 7) FROM POWER RELAY ASSEMBLY (DIAGRAM 5 OF 7) GRN WIRE GRY WIRE MAIN BATTERY MODULE 1 MAIN BATTERY MODULE 2 MAIN BATTERY MODULE 3 MAIN BATTERY MODULE 4 MAIN BATTERY MODULE 5 NCA WIRE ORG/ WIRE PNK WIRE POWER RELAY ASSEMBLY RED WIRE TO BUS BAR (DIAGRAM 7 OF 7) WHT WIRE YEL WIRE

*** BLU WIRE BMS BMS ASSEMBLY BRN WIRE BUS BAR FROM MAIN BATTERY MODULE 5 (DIAGRAM 6 OF 7) FROM POWER RELAY ASSEMBLY (DIAGRAM 5 OF 7) GRN WIRE GRY WIRE MAIN BATTERY MODULE 6 MAIN BATTERY MODULE 7 MAIN BATTERY MODULE 8 MAIN BATTERY MODULE 9 NCA WIRE ORG/ WIRE PNK WIRE RED WIRE TO MAIN BATTERY MODULE 5 (DIAGRAM 6 OF 7) WHT WIRE YEL WIRE
